磨床主轴

型号 图片 套筒外径 主轴转速 刀把规格 连续功率 详情
THG-170.01 (18kW) 170mm 20,000RPM D36/63 18kW
THG-150.01 (15kW) 150mm 30,000RPM D28/43 15kW
THG-120.14 (13kW) 120mm 30,000RPM D22/38 13kW
THG-120.01 (10kW) 120mm 30,000RPM D22/38 10kW
THG-120.02 (4.6kW) 120mm 30,000RPM D22/38 4.6kW
THG-100.04 (1.5kW) 100mm 75,000RPM D8/14 1.5kW
THG-100.01 (6.4kW) 100mm 50,000RPM D14/23 6.4kW
THG-80.01 (0.9kW) 80mm 105,000RPM D6/12 0.9kW
THGZ-80.03 (0.65kW) 80mm 120,000RPM 筒夹3~3.175mm 0.65kW
